lib_sig_lword
lib_sig_hword
uint16_t
uint16_t
Holds the general information about the library
Bit fields
Use
B1 : B0
Library Type :
00 : QTouch acquisition method
01 : QMatrix acquisition method
B2
Compiler tool chain used
0 – GCC
1 – IAR
B9 : B3
Maximum number of channels
supported by the library
B10
0 – Library supports only keys
1 – Library supports keys and
rotors
B15 : B11
Maximum number of rotors and
sliders supported by the library
Reserved
qt_lib_siginfo_t structure definitions for a QMatrix acquisition method library variant
Fields
library_version
Type
uint16_t
Comment
Holds the library version information.
Bit fields
B3 : B0
B7 : B4
B15:B8
Use
Patch version of the library
Minor version of the library
Major version of the library
lib_sig_lword
lib_sig_hword
uint16_t
uint16_t
Holds the general information about the library
Bit fields
Use
B1 : B0
Library Type :
00 : QTouch acquisition method
01 : QMatrix acquisition method
B2
Compiler tool chain used
0 – GCC
1 – IAR
B9 : B3
Maximum number of channels
supported by the library
B10
0 – Library supports only keys
1 – Library supports keys and
rotors
B15 : B11
Maximum number of rotors and
sliders supported by the library
Holds information about the X and Y lines f or a QMatrix library variant
Bit fields
Use
B4 : B0
Number of X Lines
B8 : B5
Number of Y Lines
B9
0
5.6.5 Public Functions
This section lists the public functions available in the QTouch libraries and its usage.
5.6.5.1
qt_set_parameters
This function is used to initialize the global configuration settings in the variable
qt_config_data of the QTouch and QMatrix acquisition method libraries.
void qt_set_parameters ( void )
28
8207L-AT42-05/12
